Allround Scaffolding – Versatile Solution for Industrial Maintenance

Layher the name of (German company) produces high-quality scaffolding systems in Germany. Layher has worldwide presence with more than 45 sales subsidiaries. The products are being used by industries like Construction, chemical plants, power plants, at shipyards and offshore. Now days for demanding and complex scaffolding applications – i.e. wherever conventional scaffolding technology falls short of optimal thus cost effective use, Layher Allround Scaffolding convincingly comes in with an unmatched range of advantages: unbeatably fast assembly, persuasive economic arguments and an extensive range of series-produced accessories.

The proven combination of positive and non-positive connections in a rapid and bolt-free system technology with AutoLock function facilitates connections that are automatically right-angled, obtuse-angled and acute-angled – and ensures built-in safety at the same time. Layher Allround Scaffolding has now become synonymous with modular scaffolding on the market.
Even with very difficult layouts and architecture styles and with heightened safety requirements, Allround Scaffolding is the faster, safer and more economical solution.

The Allround Versatile Scaffolding Systems
The tried-and-tested combination of positive and non-positive locking in fast, screwless system technology with the AutoLock function allows automatic right-angled, obtuse and acute-angled connections to be made – and it also incorporates security. Layher Allround Scaffolding has established itself as a synonym for modular scaffolding on the market.

The original has been continuously further developed since its introduction in 1974 and offers a convincing variety of uses: on every construction site, in industry, chemistry, power plants, shipyards and in the event area. Whether as working, protective, façade or support scaffolding, as indoor, mobile or ceiling scaffolding.

Allround scaffolding is the quick, safe and economical solution, even for the most difficult floor plans and architec-tures and where there are increased safety requirements.

More Possibilities – Layher Products and Services
Layher’s present product characteristics and services help customers achieve long-term success and increase the profitability of their companies. The Layher Allround Scaffolding has been established as a synonym for modular scaffolds on the market. The Allround Scaffolding offers unsurpassed versatility to be used in construction sites, chemical industry, power plants, aircraft, shipyards, event sector, theatres and arenas.

Allround scaffolding uses a simple, unique and bolt free connection technology. Sliding the wedge head over the rosette and inserting the wedge into the opening immediately secures the component. There is still sufficient play to secure the other end of the ledger. A hammer blow to the wedge transforms the loose connection into a superbly strong structurally rigid one. The face of the wedge head is now precisely positioned against the standard. Connections in quick to assemble and spanner less scaffolding systems make a unique combination: providing structural strength immediately on assembly and subsequent ultimate force transmission while offering a choice of automatically right – angled or splayed connections with universal safety right from the start.

Application of Layher Allround Scaffold for maintenance of Oil and Gas Industries
The Multiple Structured with different sizes operated by Refinery is currently being refurbished, and corrosion prevention experts have to treat the entire Structure time to time. Safe access to all location of main building is assured with the use of a modular scaffolding system. By using Allround Scaffold is only possibility to complete mainte-nance on time as per requirement.
The advantage lies in the speed with which not only the right angle can be automatically obtained with the system, but also variable angles can be achieved if required. This is done by fitting the ledgers in rosettes each with four holes at right angles, with four further larger holes (usually used for diagonal braces) being used to facilitate variable angles. This means that the erectors can also make connections at any angle as dictated by the conditions on site. The Scaffolder can easily, thanks to the eight possible connections in every connector, make adaptions quickly and optimally for almost any application.

These advantages is ensure the optimum conditions for effectively enclosing the Circular and rectangular structure with safe and minimal time required to construct the scaffolding. Allround Scaffolding was easily adapted to follow the contour shape of the structure without difficult to access. The erectors didn’t need to create complex tube structures, saw off tubes all the time, repeat measuring of connections or constantly align the upright elements. The wedge head provides an all in one simple yet stable connection, coupled with a logical assembly sequence and integral safety. Hot-dip galvanisation and certified quality assure Allround scaffolding top-quality products are extremely long-lived.

Layher Scaffolding Systems Pvt Ltd
Web : www.layher.co.in
